Ge-eX has two standards in our fleet being the 45ft ( 9'6'')pallet wide containers and the 45 ft pallet wide curtain-sided containers. European legislation lays down the requirements for the length and width of transport by road. The total length of the truck and trailer combination must be within 16500 mm from the kingpin till the rear end of the trailer 1200 mm and a swing radius from the kingpin from 2040 mm. Our containers have a chamfered eurocasting, which ensures that the container conforms entirely to the European legislation and is suitable for intermodal transport.

Our containers are the lightest by using special high-strength steels and lightweight floor materials. Furthermore our containers are all high cube therefore their can offer our customers the maximum achievable payload within Europe.

Dimensions of the 45ft ( 9'6'') pallet wide container

External Dimensions Internal Dimensions
length 13716 mm length 13556 mm
width 2500 mm width 2444 mm
height 2896 mm height 2695 mm
Capacity Door opening
Cubic capacity 89,2 m3 Door width 2416 mm
Euro pallet 1200mm x 800mm 33 Door height 2585 mm
ISO Pallet 1200mm x 1000mm 26 Cargo access height 2551 mm
Ratings
Max. gross weight 34.000 kgs
Max. Payload 29720 kgs
Tare weight 4260 kgs



Dimensions of the 45ft ( 9'6'') pallet wide curtain-sided container

External Dimensions Internal Dimensions
length 13716 mm length 13561 mm
width 2550 mm width 2450 mm
height 2896 mm height 2549 mm
Capacity Door opening
Cubic capacity 84 m3 Door width 2450 mm
Euro pallet 1200mm x 800mm 33 Door height 2436 mm
ISO Pallet 1200mm x 1000mm 26
Ratings Side opening dimensions
Max. gross weight 34.000 kgs length 12620 mm
Max. Payload 28130 kgs height (under toprail) 2449 mm
Tare weight 5870 kgs height (under pelmet) 2394 mm
